Architecture |
Operating System | RTOS |
Platform | STM32F103RCT6+DSE0420(Decode board) |
RAM Memory | 48KB |
Flash Memory | 256KB |
Mechanics |
Weight | 190g |
Size – Maximum (LxWxD) | 58mm x 45mm x 27mm |
System Components |
Display | x1 LED power, x1 LED two colour status , x1 Ethernet LED |
illumination | x4 illumination light |
Power |
USB | USB 2.0 Type-A, Power & Communications |
Power Adapter | 9-24V, Type 12V1A，100~240V AC 50/60HZ， Plug: China |
Keys |
Scan button, Exit trigger input |
Environmental |
IP Grade | IP54 |
Drop Test (free falls) | 1.0 m to concrete |
Tumbles | 200 hits @ 0.5m tumbles to steel plate |
Storage Temperature | -30C to 70C / -22F to 158F |
Operating Temperature | -20C to 50C / -4F to 122F |
ESD | Air +-12K Contact +-6K |
Input Technology |
|
Scan engine | Datalogic VGA DSE0420 with green spot |
Decode |
|
Symbology Support | Australia Post，Aztec Code，Codabar，Code 128，Code 39，Code 93，Composite，Data Matrix，Discrete 2 of 5，EAN-13，EAN-8，GS1 DataBar Expanded，GS1 DataBar Limited，GS1 DataBar-14，Interleaved 2 of 5，Japan Post， Matrix 2 of 5，MaxiCode，Micro PDF417，Micro QR Code，MSI，PDF417，PostNL KIX-code，QR Code，UK Royal Mai，UPC/EAN Extensions，UPC-A，UPC-E |
Reading Indicators |
|
Green Spot | Yes |
LED | Good read indication led
Fail read indication led
Configure indication led, flashing |
Beep | Beep indication |
Switch value(開關(guān)量) | Good read switching output
Fail read switching output
Configurable COM power, 5-24V COM voltage |
Software Requirements |
|
Software Input | RS232 command configure |
Soft Trigger | RS232 trigger command |
Basic Test |
|
Test Barcode | QR, DM, CODE128, CODE39 0.2-0.4m/s |
DOF |
|
Mini resolution | QR, DM, CODE128, CODE39 |
Device gift box |
|
Device, QSG, USB Type-A cable, DB9 RS232 cable, 12V1A Adapter |
Accessories(選配) |
|
USB Cable, RS232 Cable, Ethnet Cable, 12V1A Adapter |
Documentation |
|
Documentation | Quickstart, Users Guide |
Warranty |
|
12 Months Parts & labor warranty |
